The WLNJ Plunger Type Limit Switch is built for detecting the position or movement of machinery, doors, conveyors and other mechanical systems. With 10A/250VAC capacity and IP65 protection, it is a practical choice for industrial automation and equipment control.
| Detail | Information |
|---|---|
| What is it? | A mechanical limit switch used to detect the position or movement of equipment |
| Who is it for? | Electricians, automation technicians, machine builders, factories and maintenance teams |
| What problem does it solve? | Helps machines detect when a moving part reaches a specific position |
| Why is it better? | Combines a plunger mechanism with IP65 protection and a high mechanical life |
| Product Type | Plunger Type Limit Switch |
| Model | WLNJ |
| Rated Voltage | 250V |
| Maximum Current | 10A |
| Contact Arrangement | SPDT |
| IP Rating | IP65 |
| Certification | CE |
Guaranteed safe & secure checkout
| Feature | Benefit |
|---|---|
| Plunger-Type Design | Detects mechanical movement or position |
| 10A Current Rating | Suitable for compatible control applications up to the stated rating |
| 250VAC Maximum Voltage | Designed for compatible electrical circuits |
| IP65 Protection | Helps protect against dust and water jets |
| SPDT Contact Arrangement | Provides flexible switching options |
| High Mechanical Life | Supplier specifies up to 15 million mechanical operations |
| Long Electrical Life | Supplier specifies up to 750,000 electrical operations |
| Wide Operating Temperature | Rated from -40°C to +80°C |
| Fast Operating Frequency | Rated up to 120 operations per minute |
| CE Certification | Supplier lists CE certification |
| Industrial Application | Suitable for machinery and automation systems |
| Ghanaian Application | How It Helps |
|---|---|
| Factories | Helps machines detect mechanical positions |
| Conveyor Systems | Can detect movement or end positions |
| Industrial Machinery | Useful for machine control and safety-related positioning |
| Elevators | Suitable for compatible position-detection applications |
| Workshops | Useful for machinery maintenance and automation projects |
| Packaging Machines | Can detect mechanical movement |
| Production Lines | Supports automated position detection |
| Maintenance Projects | Useful as a replacement for compatible limit switches |
If you're running machinery in a busy workshop or production environment, you don't want the machine blindly moving until something breaks. 😅
A limit switch gives the control system a physical signal — basically, "Hey, this part has reached here." That simple signal can be very useful in automation.
| Specification | Details |
|---|---|
| Product Name | WLNJ Plunger Type Limit Switch |
| Model Number | WLNJ |
| Type | Electrical Plunger Limit Switch |
| Maximum Voltage | 250V |
| Maximum Current | 10A |
| IP Rating | IP65 |
| Contact Arrangement | SPDT |
| Operating Temperature | -40°C to +80°C |
| Electrical Life | 750,000 operations |
| Mechanical Life | 15,000,000 operations |
| Operating Frequency | Up to 120 times/min |
| Maximum Triggering Speed | 0.5m/s |
| Certification | CE |
| Smart Function | No |
| Place of Origin | Zhejiang, China |
| Application | Use |
|---|---|
| Conveyor Systems | Position and movement detection |
| Automation Machinery | Mechanical position feedback |
| Elevators | Compatible position detection |
| Packaging Equipment | Detecting machine movement |
| Production Machines | Position sensing |
| Industrial Equipment | Mechanical switching |
| Workshop Machinery | Equipment control |
| Automated Systems | End-position detection |
| Step | What To Do |
|---|---|
| 1. Identify the movement | Determine which moving component needs to be detected |
| 2. Position the switch | Mount the switch where the moving component can activate the plunger |
| 3. Check the contact arrangement | Identify the SPDT terminals required for your circuit |
| 4. Disconnect power | Turn off the electrical supply before wiring |
| 5. Connect the circuit | Wire according to the machine's control diagram |
| 6. Check alignment | Ensure the moving part activates the plunger correctly |
| 7. Test operation | Manually test the switch before running the machine |
| 8. Monitor performance | Confirm reliable switching during machine operation |
⚠️ Installation should be performed by a qualified electrician or automation technician.
| Item | Details |
|---|---|
| WLNJ Limit Switch | Yes |
| Plunger Mechanism | Yes |
| SPDT Contacts | Yes |
| Mounting Accessories | Not specified |
| Wiring Cable | Not specified |
| Control Equipment | Not included |
